Extract daily and monthly point precipitation
Source:vignettes/B_Point_rainfall.Rmd
B_Point_rainfall.RmdThis example shows how to build the required data files and then extract the daily rainfall at two sites. Here, one of the sites is at a rainfall gauge and the results are compared against observations.
Make netCDF file
The first step is to create the netCDF files. Here the netCDF file is created and only for daily and monthly precipitation data. Note, the monthly precipitation product can slightly differ from the monthly sum of the daily precipitation product. See for details.
Here the data is only downloaded between the dates dataFrom and dataTo. If the latter two dates were not input then data would be downloaded from 1/1/1900 to yesterday.
The netCDF file contains grids of daily rainfall for all of Australia and is used below to extract data at points of interest. Often users run build.grids once to build netCDF data files that contain all variables over the entire record length (which requires ~5GB disk storage) and then use the netCDFs grids for multiple projects, rather than re-building the netCDF for each project. Also, if build.grids is run with the the netCDF file name pointing to existing files and updateFrom=NA then the netCDF files will be updated to yesterday.
To start to create the grids, the file name for the netCDF grids needs to be defined. Here we’ll just use a temporary file. You should change this to a non-temporary file name and folder.
ncdfFilename = tempfile(fileext='.nc')Now with the inputs defined we can download the gridded data and build the netCDF file. Note, here vars is set to only download daily precipitation.
fnames = build.grids(ncdfFilename = ncdfFilename,
updateFrom = dataFrom,
updateTo = dataTo,
vars = c('precip', 'precip.monthly'))
#> ... Testing downloading of each variable.
#> Testing precip grid data.
#> Testing precip.monthly grid data.
#> ... NetCDF file will be updated as follows:
#> - New variables to add: precip precip.monthly
#> - Existing variables to modify: (none)
#> - Data will be updated from 2010-01-01 to 2010-12-31
#> ... Downloading data for each variable and importing to netcdf file:
#> Data construction FINISHED.
#> Summary of time points successfully imported (and errors).
#> Imported Errors
#> precip 365 0
#> precip.monthly 12 0
#> Total run time (DD:HH:MM:SS): 00:00:04:20Set the points for data extraction
with the data grids built, let’s set two data points to extract data at. The locations are at a groundwater bore and one rainfall gauge. Below, the coordinates are defined and then they’re convert to a spatial object and set projection to GDA94.
coordinates.data = data.frame( ID =c('Bore-10084446','Rain-63005'),
Longitude = c(153.551875, 149.5559),
Latitude = c(-28.517974,-33.4289))
sp::coordinates(coordinates.data) <- ~Longitude + Latitude
sp::proj4string(coordinates.data) = '+proj=longlat +ellps=GRS80 +no_defs'Extract daily precipitation data
Now let’s extract the daily precipitation at the two locations. The data is extracted from the netCDF file ncdfFilename and between the dates extractFrom and extractTo.
Note the netCDF file ncdfFilename must be in the working directory or the full file path must be given.
extracted.data = extract.data(ncdfFilename = ncdfFilename,
extractFrom = dataFrom,
extractTo = dataTo,
locations = coordinates.data,
vars = c('precip'),
ET.function='')
#> Extraction data summary:
#> NetCDF climate data exists from 2010-01-01 to 2010-12-31
#> Data will be extracted from 2010-01-01 to 2010-12-31 at 2 locations
#> Starting data extraction:
#> ... Building catchment weights for each grid.
#> ... Starting to extract data across all variable and locations:
#> Loading required namespace: ncdf4
#> ... Linearly interpolating gaps
#> ... Backfilling dates prior to the start of observations
#> ... Calculating area weighted results at required time-step.
#> Data extraction FINISHED.
#> Total run time (DD:HH:MM:SS): 00:00:00:24Plot the daily precipitation at each site
Now let’s plot time series of the extracted daily precipitation.
par(mfrow = c(2, 1))
site.names = c('Bore-10084446','Rain-63005')
for (i in 1:nrow(coordinates.data)){
filt = extracted.data$Location.ID == coordinates.data$ID[i]
data2plot = extracted.data$precip[filt]
dates = ISOdate(extracted.data$year[filt],
extracted.data$month[filt],
extracted.data$day[filt])
plot(dates, data2plot,
main = paste('Extracted precip. at',site.names[i]),
ylab = 'Precip [mm/d]',
xlab = 'Date',
type = 'l')
}
Check extracted data against daily precipitation gauge data
To assess the reliability of the extracted rain gauge data, let’s use the following observed precipitation for 2010 (from gauge_63005), sourced from the Australian Bureau of Meteorology.
data('raingauge')Now let’s compare the extracted rainfall against the gauge rainfall data.
The left plot shows that the gauge and extracted data plot along the 1:1. This shows that the extracted data is unbiased. The scatter does, however, show that there is some difference in the estimates. This arises because the source grids are at a 0.05 degree resolution, or about 5 km x 5 km, and this introduces some error with the gauge is not at the centre of the grid cell and the location to be extracted is not also at the centre.
par(mfrow = c(1, 2))
filt = extracted.data$Location.ID=='Rain-63005'
xdata = raingauge$Rainfall.amount..millimetres.
ydata = extracted.data$precip[filt]
plot(xdata,
ydata,
xlim = c(0,35),
ylim = c(0,35),
main ='Obs. vs. Extracted precip.',
xlab ='Obs. [mm/d]',
ylab ='Extracted precip. [mm/d]')
abline(0,1, col='grey', lty=2)
rmse = round(sqrt(mean((xdata - ydata)^2)), 2)
text(x=0, y=30, adj = c(0,0),
labels = paste('RMSE = ', rmse, 'mm/day'))
plot(cumsum(xdata),
cumsum(ydata),
xlim = c(0,175),
ylim = c(0,175),
main = 'Cum. obs. vs. Extracted precip.',
xlab = 'Obs. [mm]',
ylab = 'Extracted precip. [mm]',
type = 'l')
abline(0,1, col='grey', lty=2)
Check extracted data against monthly precipitation gauge data
Now let’s compare the gauge data at a monthly time step with the extracted monthly data and aggregated daily data to a monthly time scale.
First, let’s extract the daily data at a monthly scale
extracted.daily2monthly = extract.data(ncdfFilename = ncdfFilename,
extractFrom = dataFrom,
extractTo = dataTo,
locations = coordinates.data,
vars = c('precip'),
temporal.timestep = 'monthly',
temporal.function.name = 'sum',
ET.function='')
#> Extraction data summary:
#> NetCDF climate data exists from 2010-01-01 to 2010-12-31
#> Data will be extracted from 2010-01-01 to 2010-12-31 at 2 locations
#> Starting data extraction:
#> ... Building catchment weights for each grid.
#> ... Starting to extract data across all variable and locations:
#> ... Linearly interpolating gaps
#> ... Backfilling dates prior to the start of observations
#> ... Calculating area weighted results at required time-step.
#> Data extraction FINISHED.
#> Total run time (DD:HH:MM:SS): 00:00:00:20Next let’s extract the monthly data product.
extracted.monthly = extract.data(ncdfFilename = ncdfFilename,
extractFrom = dataFrom,
extractTo = dataTo,
locations = coordinates.data,
vars = c('precip.monthly'),
temporal.timestep = 'monthly',
ET.function='')
#> Extraction data summary:
#> NetCDF climate data exists from 2010-01-01 to 2010-12-31
#> Data will be extracted from 2010-01-01 to 2010-12-31 at 2 locations
#> Starting data extraction:
#> ... Building catchment weights for each grid.
#> ... Starting to extract data across all variable and locations:
#> ... Linearly interpolating gaps
#> ... Backfilling dates prior to the start of observations
#> ... Calculating area weighted results at required time-step.
#> Data extraction FINISHED.
#> Total run time (DD:HH:MM:SS): 00:00:00:00Now let’s aggregate the daily observed data to a monthly sum.
dates = as.Date(ISOdate( raingauge$Year,
raingauge$Month,
raingauge$Day))
raingauge.xts = xts::as.xts(raingauge$Rainfall.amount..millimetres. ,
order.by=dates)
raingauge.monthly = xts::apply.monthly(raingauge.xts, apply, 2, 'sum')Now we can compare the extracted estimates of monthly precipitation with the gauge monthly precipitation.
The top plot below shows the monthly gauged precipitation vs the extracted daily precipitation aggregated to monthly. It shows that the daily gridded data has a modest bias when aggregated to monthly (at least for 2010).
The centre plot shows the monthly gauged precipitation vs the extracted monthly precipitation. It shows a slighter greater bias at and above 100 mm/month.
The bottom plot show the extracted monthly precipitation vs the extracted daily precipitation aggregated to monthly. It shows that the daily aggregated precipitation estimates a slightly higher monthly precipitation.
par(mfrow = c(3, 1))
filt1 = extracted.daily2monthly$Location.ID=='Rain-63005'
filt2 = extracted.monthly$Location.ID=='Rain-63005'
xdata = as.numeric(raingauge.monthly)
ydata = extracted.daily2monthly$precip[filt1]
plot(xdata,
ydata,
xlim = c(0,220),
ylim = c(0,220),
main='Obs. monthly vs extracted aggregated to monthly',
xlab='Obs. [mm/month]',
ylab='Aggregated precip. [mm/month]')
abline(0,1, col='grey', lty=2)
rmse = round(sqrt(mean((xdata - ydata)^2)), 2)
text(x=0, y=200, adj = c(0,0),
labels = paste('RMSE = ', rmse, 'mm/month'))
xdata = as.numeric(raingauge.monthly)
ydata = extracted.monthly$precip[filt2]
plot(xdata,
ydata,
xlim = c(0,220),
ylim = c(0,220),
main='Obs. monthly vs extracted monthly',
xlab='Obs. [mm/month]',
ylab='Extracted precip. [mm/month]')
abline(0,1, col='grey', lty=2)
rmse = round(sqrt(mean((xdata - ydata)^2)), 2)
text(x=0, y=200, adj = c(0,0),
labels = paste('RMSE = ', rmse, 'mm/month'))
xdata = extracted.monthly$precip[filt2]
ydata = extracted.daily2monthly$precip[filt1]
plot(xdata,
ydata,
xlim = c(0,220),
ylim = c(0,220),
main='Extracted monthly vs extracted aggregated to monthly',
xlab='Extracted precip. [mm/month]',
ylab='Aggregated precip. [mm/month]')
abline(0,1, col='grey', lty=2)
